About

Find all Components of specific types

As a developer, I want to get a list of all components of specific types (and sub-types).

For example, you wan to find all http-connector operations (subType="http"), incl. patch operations (subType="rest-beta") and web-service listener (subType="wss"). You need to following query file, to query to appropriate components.

{
  "QueryFilter": {
    "expression": {
      "operator": "and",
      "nestedExpression": [
        {
          "operator": "or",
          "nestedExpression": [
              { "operator": "EQUALS", "property": "subType", "argument": ["http" ]},
              { "operator": "EQUALS", "property": "subType", "argument": ["rest-beta" ]},
              { "operator": "EQUALS", "property": "subType", "argument": ["wss" ]}
          ]
        },
        { "property": "type", "operator": "EQUALS",   "argument": [ "connector-action" ] },
        { "operator": "EQUALS", "property": "currentVersion", "argument": ["true" ]},
        { "operator": "EQUALS", "property": "deleted",        "argument": ["false" ]}
      ]
    }}
}

It is recommended to use a dedicated Workspace directory to collect all information in that directory: work\http-operations.

  1. Create that directory in your workspace.

  2. Create a file q-http-ops.json with the query from above.

bc comp get /wd work\http-operations /q q-http-ops.json /children none

This command retrieves the metadata of all components matching the query-filter, incl. their children.

  • component get - Resolve and get component metadata incl. their children.

    • Specify /children none to omit children, to get only the components returned by the query.

    • Otherwise, in that case, all profiles referenced in the operations will be fetched, too.

  • /wd Specifies the workspace directory for the current command.

  • /q Specifies the query file - in the current workspace directory - that is used to resolve the components which are subject to comp get.

  • /t compList.csv will use the compList.csv template, to render a complete list with all components.

work\http-operations\complist.csv rendered in Excel - use Pivot to get insights

Use a custom template

The default compList.csv does not contain a column for sub-type, which is quite important for the use-case above.

  1. Get the compList.csv template from the Templates\Freemarker directory where BC is installed (default templates).

  2. Paste it into your workspace directory under Templates\Freemarker as compList2.csv

bc comp get
    /wd work\http-operations
    /q q-http-ops.json
    /children none
    /t compList2.csv
